CL2X
Dimensions
| Length with barrel | 6 m |
|---|---|
| Hull height | 1.8 m |
| Height with turret | 2.5 m (w/o optics) |
| Overall width | 2.5 m |
| Ground clearance | 0.5 m |
| Approach angle | 45° |
| Departure angle | 45° |
MOBILITY
| Propulsion System | Series-hybrid |
|---|---|
| Fuel | Multifuel |
| Peak power | 500 kW |
| Peak torque | 2500 Nm |
UNCREWED OPERATION
| Remote operation | |
|---|---|
| Teloperation | |
| Autonomous operation ready |
PERFORMANCES
| Max. speed | 70 km/h |
|---|---|
| Gradient | 60% |
| Side slope | 30% |
| Overall Range on road | 500 km |
| Step | 0.7 m |
| Trench | 2 m |
| Fording depth | 1.5 m |
| Turning radius | Pivot |
DRIVELINE
| Hydraulic brakes | |
|---|---|
| Hydro-pneumatic suspensions | |
| Tracks | Rubber and steel tracks alternatives |
WEIGHT / PAYLOAD
| G.V.W. | 16 t |
|---|
ARMAMENT HITFIST® 30 UL - GENERAL FEATURES
| Type | Unmanned medium-caliber turret |
|---|---|
| Design | Compact, lightweight, for light and amphibious vehicles |
| Architecture | NGVA compliant (high interoperability) |
| Crew | 1–2 operators (display + dual joysticks) |
FIRE CONTROL
| Fully digital FCS | |
|---|---|
| Stabilized line of fire | |
| Hunter-Hunter / Hunter-Killer / Killer-Killer capabilities |
ARMAMENT
| 30 mm with Programmable Air Burst Ammunition (rounds >150 ready to fire) |
|---|
MOVEMENT
| Traverse | 360° unlimited |
|---|---|
| Elevation | -10° / +70° (up to +85° C-UAS) |
AUXILIARY ARMAMENT
| 7.62 mm coaxial MG | |
|---|---|
| Smoke launchers | |
| Anti-Tank Missile Launchers |
KEY FEATURES
| Day/night, high accuracy (moving targets) | |
|---|---|
| C-UAS capability (anti-drone) | |
| High modularity and integration |
SIGHTING
| Stabilized commander and gunner sights | |
|---|---|
| Day camera, thermal IR, eye-safe laser rangefinder |
