- Engine power increased to 1,500 hp — 5,000 Nm
- Upgraded transmission and final drives
- Widened track system
- Redesigned braking system
- New fire control system
- New Human-Machine Interface
- Advanced optronic equipment
- Innovative command, control, navigation and communication system
- 120 mm main armament with electrical servo and stabilisation system
HIGHER MOBILITY
The ARIETE C2 is an advanced evolution of the ARIETE C1 Main Battle Tank, boasting enhanced mobility, superior armour protection, and substantial firepower. Featuring a welded steel hull and a turret with composite armour, it is powered by a 1,500 hp V-12 engine.
The tank is equipped with an upgraded transmission and a widened track system. It can accommodate a crew of 4 (driver, gunner, weapon servant, commander).
ADVANCED ARMOURED PROTECTION
The ARIETE C2 features a torsion bar suspension with hydraulic bumpers and an enhanced brake system for better performance and higher GVW. Its main armament is the Leonardo 120 mm smoothbore gun, with a coaxial 7.62 mm machine gun and a 12.7 mm RCWS for air and local defence. The ARIETE C2 further features advanced optronic equipment as well as innovative command, control, navigation and communication systems.
Ariete C2
Dimensions
| Length with barrel | 9905 mm |
|---|---|
| Length without barrel | 7990 mm |
| Height hull | 1834 mm |
| Height with turret (panoramic sight) | 3011 mm |
| Overall width with fender | 3610 mm |
| Overall width without fender | 3420 mm |
| Wheelbase | 2800 mm |
| Approach angle | 40° |
| Departure angle | 40° |
| Seats | 1 + 3 |
WEIGHT / PAYLOAD / VOLUME
| Max. GVW (configuration with MPK and PSO kit) | 62,500 kg |
|---|
PERFORMANCE
| Max. speed | approx. 60 km/h |
|---|---|
| Gradient | 60% |
| Side slope | 30% |
| Range on road | 550 km |
| Step | 1.1 m |
| Trench | 3.0 m |
| Fording depth without preparation | 1.20 m |
| Fording depth with preparation | 2.1 m |
| Turning radius | Pivot |
| Power to weight ratio | 24 hp/t |
MOBILITY
| Engine | IVECO V-12 |
|---|---|
| Fuel | Diesel fuel |
| Power | 1103 kW (1500 hp) |
| Torque | 5000 Nm |
| Number of gears | 4 + 2 r. |
DRIVELINE / SUSPENSION
| Hydraulic brakes actuated with transmission retarder | |
|---|---|
| Torsion bars | 1, 2, 3, 6 and 7 road wheel stations have hydraulic shock absorbers |
SURVIVABILITY
| Laser warning system | |
|---|---|
| NBC system | |
| Night vision equipment | |
| Scalable protection kit |
TURRET — CREW
| 3 men | Commander, gunner and loader |
|---|
TURRET — ARMAMENT
| Main armament | 120/44 mm smoothbore gun |
|---|---|
| Coaxial machine gun | 1 x 7.62 mm machine gun |
| AA machine gun | 1 x 7.62 mm machine gun |
| AA pintle mounted | 1 x 12.7 mm machine gun |
| Smoke grenade launchers | 4 x 2 |
TURRET — AMMUNITION
| All standard NATO kinetic and chemical | |
|---|---|
| Ammunition stowage: | |
| 120 mm | 42 |
| Coaxial and AA MGs | >2400 rds |
| Smoke Grenade | 8 |
TURRET — ELETRICAL SERVO SYSTEMS
| Azimuth arc | unlimited |
|---|---|
| Elevation arc | -7.5° / +19° |
| Azimuth speed (acceleration) | 0.4 rad/s / (0.35 rad/s2) |
| Elevation speed (acceleration) | 0.3 rad/s / (0.8 rad/s2) |
